1
|
M8500 Magnetizer Origin: China
|
The M8500 magnetizer is used to magnetize magnetic materials, providing a maximum magnetic field of up to 90 kOe
|
Room 103, Building B2, 18 Hoang Quoc Viet, Cau Giay, Hanoi
|
ThS. Kieu Xuan Hau
|
|
2
|
ZGK-1 rapid quenching melt-spinning system
Origin: China
|
The ZGK-1 rapidly quenched melt-spinning system is used for alloy melting and the fabrication of rapidly quenched ribbons in a protective gas atmosphere
|
Room 104-105, Building B2, 18 Hoang Quoc Viet, Cau Giay, Hanoi
|
TS. Nguyen Hai Yen
|
|
3
|
ZG-0.01J middle frequency furnace Origin: China
|
The ZG-0.01J middle frequency furnace ZG-0.01J is a type of frequency furnace operating at an intermediate frequency of 4 kHz. It is used for melting alloys in a protective gas atmosphere
|
Room 104-105, Building B2, 18 Hoang Quoc Viet, Cau Giay, Hanoi
|
TS. Pham Thi Thanh
|
|
4
|
PEX-100 × 125 jaw crusher
Origin: China
|
The PEX-100 × 125 jaw crusher is a device used in the production line for sintered Nd-Fe-B magnets, responsible for the initial stage of the grinding process (coarse crushing).This machine uses mechanical jaws to break the alloy into smaller pieces in a protective gas atmosphere
|
Room 104-105, Building B2, 18 Hoang Quoc Viet, Cau Giay, Hanoi
|
ThS. Nguyen Huy Ngoc
|
|
5
|
DSB ф500 × 650 coarse crusher
Origin: China
|
The DSB ф500 × 650 coarse crusher is a piece of equipment in the production line of sintered Nd-Fe-B magnets, responsible for the coarse grinding stage following jaw crushing. The machine employs a screw shaft to grind the alloy into powder under a protective inert gas atmosphere
|
Room 106-107, Building B2, 18 Hoang Quoc Viet, Cau Giay, Hanoi
|
ThS. Nguyen Huy Ngoc
|
|
6
|
LHL-1 Jet-Mill
Origin: China
|
The LHL-1 Jet-Mill is a piece of equipment in the production line of Nd-Fe-B sintered magnets, responsible for the fine grinding stage. It uses the output material from the DSB ф500 × 650 coarse crusher. Its grinding principle is based on high-pressure compressed gas, which accelerates alloy particles, causing them to collide and break into ultrafine powder
|
Room 106-107, Building B2, 18 Hoang Quoc Viet, Cau Giay, Hanoi
|
ThS. Nguyen Huy Ngoc
|
|
7
|
ZCY25-200 automatic press with magnetic field
Origin: China
|
The ZCY25-200 automatic press with magnetic field is a piece of equipment in the production line of Nd-Fe-B sintered magnets. It is used to compact and orient Nd-Fe-B magnetic powders under a magnetic field to form green compacts for the subsequent sintering process
|
Room 108-109, Building B2, 18 Hoang Quoc Viet, Cau Giay, Hanoi
|
TS. Pham Thi Thanh
|
|
8
|
DYJ-120 isostatic press
Origin: China
|
The DYJ-120 isostatic press is a machine in the production line of sintered Nd-Fe-B magnets. It is used to increase the density of magnet compacts after the preliminary orientation pressing stage
|
Room 108-109, Building B2, 18 Hoang Quoc Viet, Cau Giay, Hanoi
|
TS. Pham Thi Thanh
|
|
9
|
RVS-15G vacuum sintering furnace Origin: China
|
The RVS-15G vacuum sintering furnace is a piece of equipment in the production line of sintered Nd-Fe-B magnets, used for sintering magnets under a high-vacuum environment
|
Room 108-109, Building B2, 18 Hoang Quoc Viet, Cau Giay, Hanoi
|
TS. Pham Thi Thanh
|
|
10
|
GSL1600-80X high-temperature vacuum furnace system
Origin: China
|
The GSL1600-80X is a vertical tube furnace system equipped with MoSi heating elements. It is widely used in materials science and chemistry laboratories for synthesizing new materials under vacuum or various gas atmospheres. The furnace temperature is controlled by a programmable controller with an accuracy of ±1 °C, supporting up to 51 programmable segments, and can reach temperatures up to 1600°C (2912°F)
|
Room 306, Building A2, 18 Hoang Quoc Viet, Cau Giay, Hanoi
|
ThS. Nguyễn Huy Ngọc
|
|
11
|
Ultra high resolution scanning electron microscopy S-4800
Origin: Japan
|
The S-4800 Hitachi is a scanning electron microscope (SEM) equipped with a cold field emission electron gun (FESEM) and an advanced electromagnetic lens system, providing high-resolution imaging. It is commonly used to characterize the properties of nanostructured materials
|
Room 202, Building A2, 18 Hoang Quoc Viet, Cau Giay, Hanoi
|
ThS. Ta Ngoc Bach
|
|
12
|
X-ray diffractometer D5000
Origin: Thermo Fisher Scientific
|
The Equinox 5000 is an X-ray diffractometer used to characterize materials, providing qualitative and quantitative phase analysis, degree of crystallinity, structural system identification, and determination of lattice parameters of the studied samples
|
Room 211, Building A2, 18 Hoang Quoc Viet, Cau Giay, Hanoi
|
PGS.TS. Tran Dang Thanh
|
|
13
|
Univex 450 sputtering systemOrigin: Germany
|
The UNIVEX 400 sputtering system from Leybold is an important instrument in thin-film fabrication based on physical deposition methods, equipped with both DC and RF power sources. It can be applied to the fabrication of single-layer as well as multilayer films for a wide range of materials. The deposited films exhibit low surface roughness, a composition close to that of the sputtering target, and high thickness accuracy
|
Room 308-309, Building A2, 18 Hoang Quoc Viet, Cau Giay, Hanoi
|
TS. Nguyen Tien Thanh
|
|
14
|
OAI SERIES 800 Photolithography SystemOrigin: USA
|
The system is designed to align the optical axis of the substrate with the mask and then expose the material coated on the substrate using a UV light source for a preset exposure time. The system consists of a control unit, an optical alignment module, and an exposure unit. The optical microscope is used for optical axis alignment, while the light source is automatically positioned at the exposure site, with the exposure time fully programmable
|
Room 308-309, Building A2, 18 Hoang Quoc Viet, Cau Giay, Hanoi
|
TS. Nguyen Tien Thanh
|
|
15
|
Spin coating systemOrigin: China
|
The spin-coating system is used for the fabrication of thin films. It allows control of spin speed, spin duration, and environmental conditions, thereby enabling precise adjustment of the thickness and properties of the deposited films
|
Room 308-309, Building A2, 18 Hoang Quoc Viet, Cau Giay, Hanoi
|
TS. Nguyen Tien Thanh
|
