High Resolution Transmission Electron Microscope

09/11/2021 - 04:34 PM

Font size

Technical parameters

Accelerating voltage: 200kV
Incandescent: LaB6
Resolution: 0.24 nm for point; 0.14 nm for lattice constant
Scanning TEM: 1 nm of resolution
Magnification: 2,000 - 1,500,000

Applications

Chracterizing microstructure, morphology, size of matter phases by high resolution transmission electron microscopy (HR - TEM)
Chracterizing crystal structures of matter phases by selected region electron diffraction (SEAD)
Take pictures of the morphology and size of matter phases using light/dark field scanning transmission electron images
Obtaining chemical element distribution spectra of matter phases by energy dispersive X-ray (EDX)
Collecting spectra and images of chemical element distribution of matter phases by pixel/line/area/mapping transmitted through scanning combined with scattered energy X-ray (STEM - EDX)
